EXPANDABLE CONTROLLER
Access control does not have to be complicated to be powerful and expandable! Webster 64 is a browser-based access control system based on Cansec’s popular Webster system, but now offers expandability of up to 64 Doors.
The Webster 64 Concierge Controller is the heart of the system, and it is available in either a 2 Door or 4 Door Configuration. To expand the system, simply add 2 or 4-door Expansion Panels as required.
We know it’s important to get in and out of a job quickly - time is money after all. Finding a suitable computer at a customer site can be time-consuming, requiring consultation with the IT Manager or other staff who fulfill this role. With Webster, there’s no software to install. Cutting Edge Simplicity at its best!
Click on the number of doors you need:
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
If you need more than 16 doors, contact sales at Cansec or one of our dealers or distributors to create a quote. Webster can be expanded up to 64 doors so there is a lot of room for growth.
 |
 |
Typical Configuration
Specifications
| Dimensions With Mounting Flange |
4.6” (W) x 4.9” (H) x 2” (D) [11.7 cm (W) x 12.4 cm (H) x 5.1 cm (D)]
5.625” (W x 4.9” (H) x 2” (D) [14.3 cm (W) x 12.4 cm (H) x 5.1 cm (D)] |
|
Weight
|
500 g (17.6 oz) |
| Operating Temperature |
0˚C to 60˚C [32˚F to 140˚F] |
|
Power Requirement
|
12 VDC / 1A [Max. Current (including 4 proximity readers with 100 mA each)] |
| Warranty | Lifetime |
Features
|
FEATURES
|
WEBSTER 64 CONTROLLER
|
| Onboard Readers | 2 or 4 |
| Expandable | Yes - 64 Readers |
|
Onboard Network TCP/IP
|
Yes
|
|
Self-contained
|
Yes
|
| Lifetime Warranty | Yes |
| Automatic Software Updates | Yes |
| On-site Tech Required for Support | No |
|
Audit Buffer (transactions)
|
25K |
|
Facility Codes (FC)
|
Unlimited
|
|
Card Capacity
|
5,000 with any FC or ID
|
|
Cansec 37-bit
|
Yes
|
|
Standard 26-bit
|
Yes
|
| Corporate 1000 - 35/48-bit |
Yes
|
|
Auto Void/Validate
|
Yes
|
| Automatic Jump Drive Backup | Yes |
|
Access Schedules
|
255
|
|
Unlock Schedules
|
Up to 64 |
|
Simultaneous Operators
|
10
|
|
Daylight Saving Time
|
Yes
|
| Double Bump Unlock |
Yes
|
|
First Man Rule
|
Yes
|
|
Door Operator Output
|
Yes
|
|
Access Profiles
|
Unlimited
|
| Email & Txt Alerts | Yes |
|
Scheduled Command
|
Yes
|
| Note: Monthly subcription fee applies. | |
Part Numbers:
